• Through the HDMI Extender, you can use one DVD to display identical image and extension of HDMI signal up to 100 meter on HDTV
  • HDCP  Compliant
  • Supports 3D pass-through
  • Supports CEC pass-through
  • Support RS-232(Bi-direction transfer)
  • Supports all frequency band IR control
  • One CAT.5 cable extension
  • Supports HDTV up to 4K2K
  • HDBaseT technology
  • Use CAT.5 cable to install easily
  • Cable Distance
  • Support HDMI DA (Local unit)
  • Function Local Remote
    HDMI In Connector HDMI A-Type Female x 1 None
    HDMI Out Connector HDMI A-Type Femalex1(DA) HDMI A-Type Female x 1
    RJ-45 Connector 1
    IR OUT 3.5φ Stereo Jack x 1
    IR2 IN 3.5φ Stereo Jack x 1
    Max. Resolution 4k2k
    Cable Distance 100 m (Max.)
    Power Adapter (Min.) DC 48V with lock
    Housing Metal
    Weight 513g 328g
    Dimensions (LxWxH) 171x120x35 mm 150x80x35 mm mm
  • 1x HDM-EPLW+ Local Unit
    1x HDM-EPRW+ Remote Unit
    1 user manual
    1x Power adapter DC 48V with lock and Power Cord (for HDM-EPXW+ )
    1x IR Blaster Cable(Peak Wavelength 940nm)
    1x IR Receiver Cable
    4x screws
    8x foot pads
