• Through the HDMI Extender, you can use one source device (HDBaseT output port) to display identical image and extension of HDMI signal up to 100 meter on HDTV
  • HDCP Compliant
  • Supports 3D pass-through
  • Supports all frequency band IR control
  • One CAT.5/6x cable extension
  • Supports resolution up to 4Kx2K
  • HDBaseT technology
  • Remote box for AVLINK's 4K(HDBaseT) Matrix model# HX-2444. HX-2488. HX-341616

  • Function HX-RW
    HDMI Out Connector HDMI A-Type Female x 1
    RJ-45 Connector 1
    IR OUT 3.5φ Stereo Jack x 1
    IR2 IN 3.5φ Stereo Jack x 1
    Max. Resolution 4Kx2K
    Cable Distance 100 m
    Power Adapter (Min.) DC 12V with lock
    Housing Metal
    Weight 308g
    Dimensions (LxWxH) 150x80x25 mm

  • 1x HX-RW Remote Unit
    1x user manual
    1x Power adapter DC 12V with lock
    1x IR Blaster Cable(Peak Wavelength 940nm)
    1x IR Receiver Cable
    2x screws
    4x foot pads
